| CODE | CR5037 |
| MOUTH FINISH | BVS 30 x 60 |
| DIAMETER | 61.2mm |
| HEIGHT | 238.5mm |
| LABEL PANEL | 115.0mm |
| PUNT DEPTH | 20.0mm |
| WEIGHT | 280g |
| 75cl FILL POINT | 37.5mm |
| PALLET LOAD | 1360 |
| LAYERS | 4 |
Available Colours
ANT, FLT
CLICK TO DOWNLOAD BOTTLE SPECS
NOTE A: CONTROLLED NECK & MOUTH REFER TO DIMENSIONAL SPECIFICATIONS FOR BVS GLASS MOUTH FINISH Norm: EN16293
LABELLING GUIDE: INDUSTRY STAKEHOLDERS INCLUDING GLASS SUPPLIERS, LABEL CONVERTERS AND CONTRACT BOTTLERS HAVE COOPERATED TO DETERMINE THE OPTIMAL LABEL SIZE AND POSITIONING ON BOTTLES AVAILABLE IN NZ.
